Información adicional
Number of fibres | 4 |
---|---|
Cable metal free | true |
Underground installation | Waterproof cable (lengthwise and sideways) with non-metallic |
Min. permitted bending radius, stationary application/permanent installation | 135.0 |
Outer diameter approx. | 9.0 |
Low smoke (acc. EN 61034-2) | false |
Flame retardant | In accordance with EN 60332-3-24 |
Euro class acidity according to EN 13501-6 | a1 |
Euro class flaming droplets/particles according to EN 13501-6 | d0 |
Smoke development class according to EN 13501-6 | s1a |
Reaction-to-fire class according to EN 13501-6 | Cca |
Radial water blocking cable | false |
Type of tube | Tight |
Longitudinal water blocking cable | false |
Colour outer sheath | Black |
Specification material outer sheath | Polyethylene (PE) |
Material outer sheath | Other |
With rodent protection | true |
Armouring | true |
With strain relief | true |
Category | OS2 |
Fibre type | Single mode 9/125 |
Number of fibres per tube | 1 |
Blow in | false |
