Información adicional
Type of electric connection | screw-type terminals |
---|---|
Three-phase over current possible | false |
Current measurement range | 0.05 |
Rated control supply voltage Us at DC | 20.4 |
Max. permitted delay-on energization time | 20 |
Min. adjustable off-delay time | 0.1 |
Voltage type for actuating | AC/DC |
With detachable clamps | true |
Number of contacts as normally open contact | 0 |
Number of contacts as change-over contact | 1 |
Number of contacts as normally closed contact | 0 |
Height | 92.0 |
Single-phase under current possible | true |
Single-phase hysteresis possible | false |
Max. permitted off-delay time | 20 |
Min. adjustable delay-on energization time | 0.1 |
Depth | 91.0 |
Width | 22.5 |
Three-phase under current possible | false |
Single-phase over current possible | true |
Contains function DC-voltage over current | true |
Rated control supply voltage Us at AC 60HZ | 20.4 |
Three-phase hysteresis possible | false |
Contains function DC-voltage under current | true |
Rated control supply voltage Us at AC 50HZ | 20.4 |
Function DC-current hysteresis | true |
Código Berdin | 90168088 |
