Información adicional
| Type of electric connection | Spring clamp connection |
|---|---|
| Min. adjustable delay-on energization time | 0 |
| Height | 103.0 |
| Width | 22.5 |
| Number of contacts as change-over contact | 1 |
| Number of contacts as normally open contact | 0 |
| Number of contacts as normally closed contact | 0 |
| Max. permitted off-delay time | 999.9 |
| Min. adjustable off-delay time | 0 |
| Max. permitted delay-on energization time | 999.9 |
| Voltage measurement range | 90 |
| With detachable clamps | true |
| Phase imbalance monitoring | true |
| Function over voltage detection | true |
| Function under voltage detection | true |
| Phase failure detection | true |
| Phase sequence monitoring | true |
| Voltage type for actuating | DC |
| Rated control supply voltage Us at DC | 24 |
| Rated control supply voltage Us at AC 60HZ | 0.0 |
| Rated control supply voltage Us at AC 50HZ | 0.0 |
| Depth | 91.0 |
