Información adicional
| Model | Other |
|---|---|
| With muting function | false |
| Height | 107.7 |
| Width | 45.0 |
| With approval according to UL | true |
| With approval for BG BIA | false |
| With approval for TÜV | true |
| Performance level acc. EN ISO 13849-1 | Level e |
| Category according to EN 954-1 | None |
| Number of outputs, signalling function, delayed, semiconductors | 1 |
| Number of outputs, signalling function, undelayed, semiconductors | 1 |
| Number of outputs, safety related, delayed, semiconductors | 0 |
| Number of outputs, safety related, undelayed, semiconductors | 0 |
| With feedback circuit | true |
| With start input | true |
| Suitable for monitoring of position switches | true |
| Evaluation inputs | 2-channel |
| With detachable clamps | true |
| Voltage type for actuating | AC/DC |
| Rated control supply voltage Us at DC | 110 |
| Rated control supply voltage Us at AC 60HZ | 110 |
| Rated control supply voltage Us at AC 50HZ | 110 |
| Rail mounting possible | false |
| Suitable for monitoring of proximity switches | true |
| Suitable for monitoring of magnetic switches | false |
| Suitable for monitoring of tactile sensors | false |
| Suitable for monitoring of optoelectronic protection equipment | false |
| Suitable for monitoring of valves | false |
| Suitable for monitoring of emergency-stop circuits | false |
| Depth | 124.3 |
