Información adicional
Number of semiconductor outputs with signalling function | 0 |
---|---|
Performance level acc. EN ISO 13849-1 | Level e |
Material housing | Plastic |
Height of sensor | 36.0 |
With monitoring function downstream switching devices | false |
Mechanical mounting condition for sensor | Quasi-flat |
Protected switch distance ON | 5.0 |
Number of protected semiconductor outputs | 0 |
Voltage type | DC |
Ambient temperature | -25 |
Explosion safety category for dust | None |
Protected switch distance OFF | 15.0 |
Width sensor | 26.0 |
Number of protected contact energized outputs | 1 |
Number of contact energized outputs with signalling function | 1 |
Length of sensor | 13.0 |
Type of electric connection | Other |
Suitable for safety functions | true |
Cross-/short circuit identification possible | true |
Explosion safety category for gas | None |
Código Berdin | 90172690 |
