Información adicional
Number of contacts as change-over contact | 1 |
---|---|
Rated operation current Ie at AC-15, 24 V | 6 |
Ambient temperature during operating | -25 |
Rated operation current Ie at DC-13, 24 V | 3 |
Explosion safety category for gas | None |
Height of sensor | 27.0 |
With status indication | false |
Output electronic | false |
Material housing | Plastic |
Type of control element | Plunger |
Number of safety auxiliary contacts | 1 |
Number of contacts as normally closed contact | 1 |
Alignment of the control element | Roller cam straight |
Type of interface for safety communication | None |
Type of electric connection | Cable entry metrical |
Number of contacts as normally open contact | 1 |
Length of sensor | 59.2 |
Explosion safety category for dust | None |
Rated operation current Ie at DC-13, 125 V | 0.55 |
Type of interface | None |
Width sensor | 30.0 |
Suitable for safety functions | true |
Forced opening | true |
Switching function latching | false |
Coating housing | Other |
Degree of protection (IP) | IP20 |
Construction type housing | Other |
Switching function | Quick-break switch |
Código Berdin | 10122362 |
