Información adicional
Height | 140.0 |
---|---|
Overload release current setting | 70 |
Width | 55.0 |
Type of electrical connection of main circuit | Screw connection |
Degree of protection (IP) | IP20 |
Depth | 149.0 |
Adjustment range undelayed short-circuit release | 1040 |
Rated operation power at AC-3, 230 V | 22.0 |
Rated short-circuit breaking capacity lcu at 400 V, AC | 65.0 |
Device construction | Einbaugerät Festeinbautechnik |
With integrated under voltage release | false |
Rated operation power at AC-3, 400 V | 37.0 |
Number of poles | 3 |
Rated permanent current Iu | 80.0 |
Rated operating voltage | 690 |
Phase failure sensitive | true |
With integrated auxiliary switch | false |
Type of control element | Turn button |
Switch off technique | Magnetic |
With thermal protection | true |
Código Berdin | 13002350 |
