Información adicional
Height | 140.0 |
---|---|
Type of control element | Turn button |
Width | 55.0 |
Overload release current setting | 54 |
Degree of protection (IP) | IP20 |
With integrated auxiliary switch | false |
With thermal protection | true |
Rated operation power at AC-3, 230 V | 18.5 |
Depth | 149.0 |
Device construction | Einbaugerät Festeinbautechnik |
With integrated under voltage release | false |
Rated operation power at AC-3, 400 V | 30.0 |
Adjustment range undelayed short-circuit release | 845 |
Rated permanent current Iu | 65.0 |
Rated operating voltage | 690 |
Phase failure sensitive | true |
Rated short-circuit breaking capacity lcu at 400 V, AC | 65.0 |
Type of electrical connection of main circuit | Screw connection |
Switch off technique | Magnetic |
Number of poles | 3 |
Código Berdin | 13002349 |
