Información adicional
Height | 97.0 |
---|---|
Depth | 97.0 |
Width | 45.0 |
Rated short-circuit breaking capacity lcu at 400 V, AC | 100.0 |
Degree of protection (IP) | IP20 |
Adjustment range undelayed short-circuit release | 16 |
Type of electrical connection of main circuit | Screw connection |
Rated operation power at AC-3, 230 V | 0.18 |
Number of poles | 3 |
Device construction | Einbaugerät Festeinbautechnik |
With integrated under voltage release | false |
Rated operation power at AC-3, 400 V | 0.37 |
Type of control element | Turn button |
Rated permanent current Iu | 1.25 |
Rated operating voltage | 690 |
Phase failure sensitive | true |
With thermal protection | true |
With integrated auxiliary switch | false |
Switch off technique | Magnetic |
Overload release current setting | 0.9 |
Código Berdin | 10132396 |
