Additional information
| Rated permanent current Iu | 100.0 |
|---|---|
| Number of auxiliary contacts as normally closed contact | 0 |
| Motor drive optional | true |
| Motor drive integrated | false |
| Complete device with protection unit | true |
| Type of control element | Rocker lever |
| Position of connection for main current circuit | Other |
| Number of poles | 4 |
| Number of auxiliary contacts as change-over contact | 0 |
| Number of auxiliary contacts as normally open contact | 0 |
| DIN rail (top hat rail) mounting optional | true |
| Rated voltage | 600 |
| Suitable for DIN rail (top hat rail) mounting | true |
| Device construction | Einbaugerät Festeinbautechnik |
| Type of electrical connection of main circuit | Other |
| Integrated earth fault protection | true |
| Adjustment range undelayed short-circuit release | 150 |
| Adjustment range short-term delayed short-circuit release | 60 |
| Overload release current setting | 40 |
| Rated short-circuit breaking capacity lcu at 400 V, 50 Hz | 55.0 |
| Degree of protection (IP) | IP40 |
