Información adicional
Rated permanent current Iu | 150.0 |
---|---|
Number of auxiliary contacts as normally open contact | 0 |
Complete device with protection unit | true |
Motor drive integrated | false |
Number of auxiliary contacts as change-over contact | 0 |
Type of control element | Rocker lever |
Number of auxiliary contacts as normally closed contact | 0 |
Number of poles | 3 |
Position of connection for main current circuit | Other |
Motor drive optional | true |
Rated voltage | 690 |
DIN rail (top hat rail) mounting optional | true |
Degree of protection (IP) | IP40 |
Integrated earth fault protection | false |
Type of electrical connection of main circuit | Other |
Suitable for DIN rail (top hat rail) mounting | true |
Adjustment range undelayed short-circuit release | 750 |
Device construction | Einbaugerät Festeinbautechnik |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz | 55.0 |
Overload release current setting | 150 |
Código Berdin | 90169782 |
