Información adicional
Rated permanent current Iu | 50.0 |
---|---|
Rated voltage | 690 |
Degree of protection (IP) | IP40 |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz | 36.0 |
Overload release current setting | 35 |
Type of control element | Rocker lever |
Integrated earth fault protection | false |
Number of auxiliary contacts as normally closed contact | 0 |
Suitable for DIN rail (top hat rail) mounting | true |
Device construction | Einbaugerät Festeinbautechnik |
DIN rail (top hat rail) mounting optional | true |
Complete device with protection unit | true |
Number of auxiliary contacts as normally open contact | 0 |
Motor drive integrated | false |
Motor drive optional | true |
Adjustment range undelayed short-circuit release | 250 |
Position of connection for main current circuit | Front side |
Number of poles | 4 |
Number of auxiliary contacts as change-over contact | 0 |
Código Berdin | 90143874 |
