Información adicional
| Rated control supply voltage Us at AC 50HZ | 380.0 |
|---|---|
| Rated control supply voltage Us at AC 60HZ | 380.0 |
| Voltage type for actuating | AC |
| Rated operation current Ie at AC-1, 400 V | 700 |
| Rated operation current Ie at AC-3, 400 V | 630 |
| Rated operation power at AC-3, 400 V | 335.0 |
| Rated operation current Ie at AC-4, 400 V | 610 |
| Rated operation power NEMA | 389.8143375 |
| Modular version | true |
| Number of auxiliary contacts as normally open contact | 4 |
| Number of auxiliary contacts as normally closed contact | 4 |
| Number of normally closed contacts as main contact | 0 |
| Number of main contacts as normally open contact | 3 |
