Información adicional
Voltage type for actuating | AC |
---|---|
Rated operation power at AC-3, 400 V | 15.0 |
Rated operation current Ie at AC-1, 400 V | 50 |
Number of main contacts as normally open contact | 3 |
Modular version | true |
Rated operation current Ie at AC-3, 400 V | 32 |
Rated operation current Ie at AC-4, 400 V | 22 |
Number of auxiliary contacts as normally closed contact | 1 |
Number of auxiliary contacts as normally open contact | 1 |
Rated operation power NEMA | 14.709975 |
Type of electrical connection of main circuit | Screw connection |
Código Berdin | 00027119 |
