Información adicional
Rated control supply voltage Us at AC 50HZ | 220.0 |
---|---|
Modular version | true |
Rated control supply voltage Us at AC 60HZ | 220.0 |
Rated control supply voltage Us at DC | 220 |
Voltage type for actuating | AC/DC |
Number of main contacts as normally open contact | 3 |
Rated operation current Ie at AC-3, 400 V | 185 |
Rated operation current Ie at AC-1, 400 V | 215 |
Rated operation current Ie at AC-4, 400 V | 160 |
Rated operation power at AC-3, 400 V | 90.0 |
Rated operation power NEMA | 110.3248125 |
Rated operation power at AC-4, 400 V | 90.0 |
Number of auxiliary contacts as normally open contact | 2 |
Number of auxiliary contacts as normally closed contact | 2 |
Type of electrical connection of main circuit | Rail connection |
Código Berdin | 06360640 |
