Información adicional
| Number of poles | 4 |
|---|---|
| Rated current | 63 |
| Width in number of modular spacings | 3 |
| Additional equipment possible | true |
| Surge current capacity | 1.0 |
| Built-in depth | 70.0 |
| Ambient temperature during operating | -25 |
| Pollution degree | 2 |
| Connectable conductor cross section multi-wired | 1.5 |
| With interlocking device | false |
| Short-time delayed tripping | false |
| Degree of protection (IP) | IP20 |
| Connectable conductor cross section solid-core | 1.5 |
| Selective protection | false |
| Rated fault current | 30.0 |
| Rated insulation voltage Ui | 460 |
| Rated voltage | 400 |
| Mounting method | DIN rail |
| Rated impulse withstand voltage Uimp | 4.0 |
| Código Berdin | 90173242 |
