Información adicional
| Release characteristic | C |
|---|---|
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 10.0 |
| Over voltage category | 3 |
| Concurrently switching N-neutral | false |
| Additional equipment possible | true |
| Width in number of modular spacings | 1 |
| Connectable conductor cross section multi-wired | 0.75 |
| Degree of protection (IP) | IP20 |
| Number of poles (total) | 1 |
| Suitable for flush-mounted installation | false |
| Built-in depth | 70.0 |
| Number of protected poles | 1 |
| Ambient temperature during operating | -40 |
| Rated voltage | 400 |
| Voltage type | AC/DC |
| Pollution degree | 3 |
| Rated current | 40 |
| Connectable conductor cross section solid-core | 0.75 |
| Rated insulation voltage Ui | 440 |
| Rated impulse withstand voltage Uimp | 4.0 |
| Current limiting class | 3 |
| Rated short-circuit breaking capacity Icn EN 60898 at 400 V | 10.0 |
| Código Berdin | 90173088 |
