Automático magnetotérmico 230 V 6 kA, 1+N polos/1 (5SL6010-7)

81,24 IVA incluido

Automático magnetotérmico 230 V 6 kA, 1+N polos/1 mód. C10

24 disponibles

SKU: 5SL6010-7 Categoría:

Información adicional

Release characteristic

C

Pollution degree

2

Over voltage category

3

Rated short-circuit breaking capacity Icn EN 60898 at 230 V

6.0

Degree of protection (IP)

IP20

Width in number of modular spacings

1

Connectable conductor cross section multi-wired

0.75

Additional equipment possible

true

Number of protected poles

1

Suitable for flush-mounted installation

false

Built-in depth

70.0

Current limiting class

3

Concurrently switching N-neutral

true

Rated voltage

230

Voltage type

AC

Number of poles (total)

2

Rated impulse withstand voltage Uimp

4.0

Connectable conductor cross section solid-core

0.75

Rated insulation voltage Ui

250

Rated current

10

Ambient temperature during operating

-25

Rated short-circuit breaking capacity Icn EN 60898 at 400 V

6.0

Código Berdin

13011455
