Información adicional
| Rated operation current Ie at 40 °C Tu | 171 |
|---|---|
| Internal bypass | true |
| Rated power three-phase motor, inline, at 230 V | 45.0 |
| Rated power three-phase motor, inline, at 400 V | 90.0 |
| Rated power three-phase motor, inside delta, at 230 V | 90.0 |
| Rated surrounding temperature without derating | 40 |
| Function | Single direction |
| Rated power three-phase motor, inside delta, at 400 V | 160.0 |
| Torque control | false |
| Rated control supply voltage Us at AC 60HZ | 110 |
| Rated control supply voltage Us at AC 50HZ | 110 |
| Rated operating voltage Ue | 200 |
| Voltage type for actuating | AC |
| Release class | Adjustable |
| Degree of protection (IP) | IP00 |
| Código Berdin | 90163844 |
