Información adicional
| Kind of motor starter | Reversing starter |
|---|---|
| Rated control supply voltage Us at DC | 20.4 |
| Voltage type for actuating | DC |
| Rated operation power at AC-3, 400 V | 4.0 |
| Rated operation current Ie | 9 |
| Rated operation current at AC-3, 400 V | 9 |
| Overload release current setting | 1.5 |
| Release class | CLASS 10 |
| Type of electrical connection of main circuit | Other |
| Type of electrical connection for auxiliary- and control current circuit | Other |
| With transformer | false |
| Degree of protection (IP) | IP65 |
| Supporting protocol for ASI | true |
| Width | 294.0 |
| Height | 215.0 |
| Depth | 159.0 |
