Información adicional
Release characteristic | C |
---|---|
Number of protected poles | 2 |
Voltage type | AC/DC |
Number of poles (total) | 2 |
Degree of protection (IP) | IP20 |
Additional equipment possible | true |
Concurrently switching N-neutral | false |
Built-in depth | 70.0 |
Width in number of modular spacings | 2 |
Pollution degree | 3 |
Suitable for flush-mounted installation | false |
Over voltage category | 3 |
Rated insulation voltage Ui | 440 |
Rated current | 6 |
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 15.0 |
Rated short-circuit breaking capacity Icn EN 60898 at 400 V | 10.0 |
Rated voltage | 400 |
Ambient temperature during operating | -25 |
Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 10.0 |
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V | 15.0 |
Código Berdin | 90148786 |
